In this we are going to see a basic example of decision tree implementation in Python Programming Language.
#note: need a Comps.csv file in dir
from numpy import log2 as log
import pandas as pd
import numpy as np
import pprint
def find_entropy(df):
Class = df.keys()[-1]
entropy = 0
values = df[Class].unique()
for value in values:
fraction = df[Class].value_counts()[value]/len(df[Class])
entropy += -fraction*np.log2(fraction)
return entropy
def find_entropy_attribute(df,attribute):
Class = df.keys()[-1]
target_variables = df[Class].unique()
variables = df[attribute].unique()
entropy2 = 0
for variable in variables:
entropy = 0
for target_variable in target_variables:
num = len(df[attribute][df[attribute]==variable][df[Class] ==target_variable])
den = len(df[attribute][df[attribute]==variable])
fraction = num/(den+eps)
entropy += -fraction*log(fraction+eps)
fraction2 = den/len(df)
entropy2 += -fraction2*entropy
return abs(entropy2)
def find_winner(df):
gain = []
for key in df.keys()[:-1]:
gain.append(find_entropy(df)-find_entropy_attribute(df,key))
return df.keys()[:-1][np.argmax(gain)]
def get_subtable(df, node,value):
return df[df[node] == value].reset_index(drop=True)
def buildTree(df,tree=None):
Class = df.keys()[-1]
node = find_winner(df)
attValue = np.unique(df[node])
if tree is None:
tree={}
tree[node] = {}
for value in attValue:
subtable = get_subtable(df,node,value)
clValue,counts = np.unique(subtable[Class],return_counts=True)
if len(counts)==1:
tree[node][value] = clValue[0]
else:
tree[node][value] = buildTree(subtable)
return tree
eps = np.finfo(float).eps
df = pd.read_csv('Comps.csv')
print(df)
tree= buildTree(df)
pprint.pprint(tree)
#ENJOY CODING
